| Model | RN-3015D/RN-4015D/RN-4020D/RN-6015D/RN-6020D |
| Working size | 3000*1500mm/4000*1500mm/4000*2000mm/6000*1500mm |
| Laser power | 1500W/3000W/6000W/12000W |
| Positioning accuracy | ±0.05mm |
| Cooling model | water-cooling ( Hanli/ S&A) |
| Repeatability | ±0.02m/min |
| Maximun |
100m/min |
|
NO. |
Item |
Description |
|
1 |
RN-3015D |
Working area:3000mm*1500mm Cutting accuracy : ( ±0.02mm） |
|
2 |
Laser source |
MAX/ Raycus 1500W/3000W/6000W/12000W |
|
3 |
Laser head |
Raytools BM110/BOCI 421 |
|
4 |
Control system |
Raytools X3S/CYPCUT 2000/4000 |
|
5 |
Y axis driving system |
INOVANCE 850w |
|
6 |
X axis driving system |
INOVANCE 850w |
|
7 |
Z axis driving system |
INOVANCE 400w |
|
8 |
Motor reducer |
Japan Shimpo/Motovario |
|
9 |
Electric components |
Zhengtai |
|
10 |
Guide rail |
Hiwin(marked) |
|
11 |
Gear rack |
YYC (marked) |
|
12 |
Proportional valve |
Jiangrui |
|
13 |
Computer |
Standard Industrial PC |
|
14 |
Beam |
Aviation aluminum profile beam |
|
15 |
Working bed |
Heavy duty Tube welding wok bed |
|
16 |
Chiller |
S&A |
|
17 |
Max Idle Speed |
80 m/min 100m/min |
|
18 |
Max Acceleration |
1.0G /1.2G |
|
19 |
Positioning Accuracy |
±0.03mm |
|
20 |
Re-Positioning Accuracy |
±0.02mm |
|
21 |
Lubrication System |
One Touch Automatic Lubrication |
|
22 |
Power Supply |
Three-phase 220V/380V/50Hz/60Hz |
|
23 |
Gross Weight |
2000 Kg |
|
24 |
Machine Size |
4600mm*2300*1800mm |
